3. Undo the check valve seat (1) and pull out the check valve (2) and spring (3) in order.
R52WA92A
5. Undo the plug (1) and remove the spring (2), unload valve (3) and plate (4).
Seat Tightening torque......... 49~58.8 N•m 5~6 kgf-m 36~43.2 ft-lb
REAR HSTAXLE
6. At this moment, check the O-ring at the oil flow hole that touches the hydraulic cylinder body. R52WA91A
4. Unscrew the seat plug (1) and remove the poppet valve (2) and spring (3). Seat plug Tightening torque......... 39.2~58.8 N•m 4.0~6.0 kgf-m 28.8~43.2 ft-lb
HYDRAULIC STEERING SYSTEM
STEERING SYSTEM FRONT AXLE
FRONT BRAKE AXLE
REAR BRAKE AXLE
R52WA93A
HYDRAULIC ELECTRIC & DIAGNOSIS SYSTEM
R52WA94A
A/C AND INDEX HEATER
7. When installing the control valve assembly, set the distance (A) between the pusher assembly (1) and joint plate (2) to 20+00.2.
