REAR AXLE - DISASSEMBLY, SERVICING AND ASSEMBLY

6.2.3. REAR DIFFERENTIAL INSTALLATION

bolt (M10) ...................... 48.0 ~ 55.9 N•m 4.9 ~ 5.7 kgf-m 35.3 ~ 41.0 ft-lb

Important

• Apply ThreeBond® 1372 or equivalent onto the thread, and tighten the bolt to the ����� torque.

1. Install the both differential bearing cases and differential assembly simultaneously. When installing the bearing cases, make sure to install the left part to the left section and right part to the right section.

2. Bearing case (LH) (boss-large) → Install to the left side of the transmission case.

3. Bearing case (RH) (boss-small) → Install to the right side of the transmission case.
