HYDRAULIC SYSTEM - DISASSEMBLY, SERVICE AND ASSEMBLY
R69WA62A
8. Pull out the mounting spring pin (2) for the hydraulic arm (1) to disconnect the hydraulic arm and hydraulic rod (3).
TRANSMISSION TRANSMI SSION
10. Unscrew the lever support mounting bolt (1) and turn the lever support assembly to loosen the mounting screw (2). Then, disconnect the position control lever arm (3) and remove the lever support assembly (4).
REMARK
TRANSMI HST REAR HSTAXLE
•
Apply Loctite® 5060 or equivalent sealant to the mounting screw when the reinstalling it. Apply liquid gasket to the mating surfaces of between of the lever supprot and hydraulic cylinder.
Dealer Copy -- Not forSSION Resale
•
CLUTCH
R69WA66A
FRONT STEERING AXLE SYSTEM
FRONT BRAKE AXLE
REAR BRAKE AXLE
R69WA63A
A/C AND INDEX HEATER
HYDRAULIC ELECTRIC & DIAGNOSIS SYSTEM
HYDRAULIC STEERING SYSTEM
R69WA64A
R69WA65A
9. Remove the snap ring (1), position control link (2) and mounting shaft (3).
DR72-W00
329 of 450
11-45
