HYDRAULIC SYSTEM - DISASSEMBLY, SERVICE AND ASSEMBLY
GENERAL
A Driven shaft Suction section
ENGINE
section Drive shaft
CLUTCH
T46WA80A
T46WA85A
5. Check the back-up ring in the thrust block and the seal ring for damage.
9. Be careful with the direction of the drive shaft and driven
6. Check the bushing of the thrust block for wear. Also, check if the position of bushing has been changed.
10. Tighten the cover tightening bolt to the specified torque.
• . If the groove on the bushing of the section A is not aligned with the groove of the thrust block, the position of bushing has been changed. In this case, replace the bushing.
shaft of the gear shaft. • Bolt tightening torque.......... 44.1 N•m 4.5 kgf-m 32.5 ft-lb
Dealer Copy -- Not for Resale
TRANSMI SSION TRANSMISSION TRANSMI SSION HST REAR HSTAXLE REAR BRAKE AXLE
Drain
7. Check the dowel pin prior to assembly of the front cover, body, middle flange and rear cover.
Suction
Drain section Dowel
T46WA82A
8. When assembling the thrust block, the seal should face the drain section and the section without the seal should contact with the gear.
