TRANSMI SSION HST
REMARK •
REAR HSTAXLE REAR BRAKE AXLE
7. Install the steering cylinder again. If necessary, adjust the toe-in to the specification (2 ~ 8 mm). At this time, unscrew the mounting nut (1) of the ball joint end and turn the rack end (2) for adjustment. After adjustment, tighten the mounting nut of the ball joint end firmly. The steering cylinder is supposed to be replaced as one unit. If oil leaks from it or it is faulty, replace it as one unit.
REMARK • A03W914A
4. Unscrew the steering cylinder bracket mounting bolts (1) to remove the steering cylinder. Mounting bolt tightening torque.......... 24.5 N•m 2.5 kgf-m 18.1 ft-lb
When installing the steering cylinder and ball joint (tie rod end), apply thread lock (LOCTITE® #271 or equivalent) to the threads and tighten them to the ���� torque. Tightening torque.............. 161.7 N•m 16.5 kgf-m 118.8 ft-lb
HYDRAULIC STEERING SYSTEM HYDRAULIC ELECTRIC & DIAGNOSIS SYSTEM A/C AND INDEX HEATER
A03W915A
5. Remove the steering cylinder assembly. 6. Assemble in the reverse order of disassembly.
10-26284 of 450
DR72-W00
Dealer Copy -- Not for Resale
3. Remove the steering cylinder hydraulic hoses (LH/RH)(1).
STEERING SYSTEM FRONT AXLE
FRONT BRAKE AXLE
R69WA35A
R69WA34A
TRANSMI SSION TRANSMISSION
CLUTCH
ENGINE
GENERAL
SAFETY FIRST
STEERING SYSTEM - DISASSEMBLY, SERVICE AND ASSEMBLY
