FRONT AXLE - DISASSEMBLY, SERVICE AND ASSEMBLY
ENGINE
GENERAL
REMARK
A53W862A
When removing the rear bracket, be careful not to miss the thrust collar (1) and O-ring (2) in it.
R69W944A
6. Support the front axle support with a hydraulic jack or hoist. Unscrew the front bracket mounting bolts (1) and rear bracket nuts (2) to separate the front axle assembly from the main body.
A53W863A
•
When installing the DX bushing in the rear bracket, align the greasing hole with the bushing hole.
• Mounting bolt, nut tightening torque.......... 123.6 ~ 147 N•m 12.6 ~ 15 kgf-m 91.1 ~ 108.5 ft-lb
HYDRAULIC STEERING SYSTEM
STEERING SYSTEM FRONT AXLE
FRONT BRAKE AXLE
REAR BRAKE AXLE
REAR HSTAXLE
TRANSMI SSION HST
TRANSMI SSION TRANSMISSION
•
A53W878A
A/C AND INDEX HEATER
HYDRAULIC ELECTRIC & DIAGNOSIS SYSTEM
•
When removing the front bracket, be careful not to miss the adjusting plate in it. Also, when installing the DX bushing in the front bracket, align the grease nipple mounting hold with the bushing hole.
R69W945A
7. Support the front axle support with a hoist in a safe place. If necessary, separate the front bracket (1) and rear bracket (2).
9-28 252 of 450
