REAR AXLE - DISASSEMBLY, SERVICING AND ASSEMBLY
R69W735A
4. Seat the steel ball (1) onto the groove of the transmission case firmly and install the spring (2). Then, align the brake cam (3) and groove with the steel ball and pull the spring (2) to fix it. (When installing the steel ball, apply a sufficient amount of grease to the groove.)
FRONT BRAKE AXLE
REAR BRAKE AXLE
REAR HSTAXLE
TRANSMI SSION HST
Dealer Copy -- Not for Resale
TRANSMI SSION TRANSMISSION
R69W734A
REMARKS
HYDRAULIC ELECTRIC & DIAGNOSIS SYSTEM
HYDRAULIC STEERING SYSTEM
STEERING SYSTEM FRONT AXLE
BRAKE CAM PLATE IDENTIFICATION
A/C AND INDEX HEATER
R52W636A
•
Install the brake cam plate marked with (R) to the right side.
