4. Insert the remaining side gear (1) followed by the differential washer (2) onto it. Then, install the differential case cap (3), and tighten the bolts (4) securely in diagonal direction to the specified torque. ����������= bolt (M10)....................... 48.0 ~ 55.9 N•m 4.9 ~ 5.7 kgf-m 35.3 ~ 41.0 ft-lb
HYDRAULIC STEERING SYSTEM
STEERING SYSTEM FRONT AXLE
IMPORTANT • S76W668A
3. Install the differential pinion shaft 2 (1), pinion (2) and washer in order.
•
The thickness of the differential washer should be same to the one which were previously installed to the side gear. Apply ThreeBond® 1372 or equivalent onto the thread.
IMPORTANT •
Make sure that the key groove on the shaft is aligned with the case groove. Also, the protrusion of the washer should be into the groove.
