R69W729A
R52W614A
R52W630A
REAR BRAKE AXLE
6. Remove the cam plate spring (1). Then, remove the cam plate (2) and steel ball (3).
R69W730A
HYDRAULIC ELECTRIC & DIAGNOSIS SYSTEM
7. Unscrew the differential bearing case mounting bolt (1) to remove the differential bearing case (2).
IMPORTANT
DR72-W00
205 of 450
Before removing the differential bearing case, note the amount of installed shims so that the same amount of shims can be installed later.
A/C AND INDEX HEATER
•
HYDRAULIC STEERING SYSTEM
FRONT STEERING AXLE SYSTEM
FRONT BRAKE AXLE
5. Unscrew the rear axle case mounting bolts and nuts (1) and pull out the rear axle case slightly. Then, hold and remove it using a tool, such as a hoist. (M12 bolt: 11 EA, nut: 2 EA)
REAR HSTAXLE
TRANSMI HST
Dealer Copy -- Not forSSION Resale
TRANSMISSION TRANSMI SSION
R69W728A
CLUTCH
ENGINE
GENERAL
SAFETY FIRST
REAR AXLE - DISASSEMBLY, SERVICING AND ASSEMBLY
7-19
