R69W720A
R52W614A
R69W721A
TRANSMI SSION HST REAR HSTAXLE REAR BRAKE AXLE FRONT BRAKE AXLE STEERING SYSTEM FRONT AXLE
5. Support the rear axle case with a hoist and unscrew the mounting bolt (1) and nut of the rear axle case. Tap the rear axle case gently with a rubber hammer to push it out slightly. Then, hold and pull it out. (M12 bolt: 11 EA, nut: 2 EA) (When reinstalling the rear axle case, apply sealant (Loctite® 5060 or equivalent) to its mating surface.) Mounting bolt, nut
6. Pull out the O-ring (1) and remove the brake disc (2) and plate (3).
tightening torque........... 102.9 ~ 117.6 N•m 10.5 ~ 12 kgf-m 75.6 ~ 86.4 ft-lb Stud bolt
HYDRAULIC STEERING SYSTEM
tightening torque..........
3 4.3 ~ 49.0 N•m 3.5 ~ 5.0 kgf-m 25.2 ~ 36.0 ft-lb R69W722A
A/C AND INDEX HEATER
HYDRAULIC ELECTRIC & DIAGNOSIS SYSTEM
7. Pull out the snap ring (1) and remove the 9 gear shaft (2).
7-16 202 of 450
DR72-W00
Dealer Copy -- Not for Resale
R69W719A
TRANSMI SSION TRANSMISSION
CLUTCH
ENGINE
GENERAL
SAFETY FIRST
REAR AXLE - DISASSEMBLY, SERVICING AND ASSEMBLY
