TRANSMISSION - DISASSEMBLY, SERVICE AND ASSEMBLY
R69W5C5A
REAR HSTAXLE
R69W5C9A
5. Undo the shift rod stopper (1) and remove the plug (2), snap ring (3), PTO shift fork (4), PTO shift rod (5), steel ball (6), spring (7).
FRONT BRAKE AXLE
REMARK •
STEERING SYSTEM FRONT AXLE
REAR BRAKE AXLE
R69W5C6A
7. Remove the PTO shaft (1) in the transmission case by tapping outside direction to remove the ball bearing (2), thrust spacer (3), 58 gear needle bearing (4), shifter (PTO 1 stage model), 58 plain gear (PTO 2 stages model) (5) from the transmission case.
•
A/C AND INDEX HEATER
HYDRAULIC ELECTRIC & DIAGNOSIS SYSTEM
HYDRAULIC STEERING SYSTEM
•
When installing the thrust spacer, its groove should face the gear side. Apply ThreeBond® 1372 or equivalent adhesive when the sleeve install to the PTO shaft inside. Make sure to apply grease on the mating surface of oil seal.
R69W5C7A
6. Unscrew the mounting bolts (1) of PTO bearing case and remove the PTO bearing case (2).
REMARK •
Apply liquid gasket (Dow Corning® 780 or equivalent) to the mating surfaces of PTO bearing case.
5-30 156 of 450
DR72-W00
