5. Insert the bearing case (2) to the reverse shaft (1). Then, put the stopper (3) into the reverse shaft hole and tighten the mounting bolt (4).
REMARK •
Apply adhesive for preventing bolt & nut looseness on the bolt.
REAR HSTAXLE
TRANSMI SSION HST
R69W5B5A
R69W5B2A
R69W5B6A
FRONT BRAKE AXLE
REAR BRAKE AXLE
7. Install the counter shaft (1).
HYDRAULIC STEERING SYSTEM
STEERING SYSTEM FRONT AXLE
R69W5B3A
A/C AND INDEX HEATER
HYDRAULIC ELECTRIC & DIAGNOSIS SYSTEM
R69W5B7A
R69W5B4A
8. Insert the spring, steel ball and shift rod (for 1st / 3rd gear) to the bearing case in order. Then, after insert the shift fork (for 2nd / R gear) (1), shift fork (for 1st / 3rd gear) (2) and shift rod (for 1st / 3rd gear) (3) to the shiter in order, set the spring pin (4) to assembly.
6. Install the 35 gear inner ring (1), shifter (2), 26 gear inner ring (3), thrust spacer (4), snap ring (5) to the 11 gear shaft.
5-28 154 of 450
DR72-W00
Dealer Copy -- Not for Resale
TRANSMI SSION TRANSMISSION
CLUTCH
ENGINE
GENERAL
SAFETY FIRST
TRANSMISSION - DISASSEMBLY, SERVICE AND ASSEMBLY
