TRANSMISSION - SPECIFICATIONS
1.3 SEALANT AND ADHESIVE SPECIFICATIONS Item
Specification GENERAL
Location Liquid gasket
Loctite® 5060 or equivalent
* Clutch housing, transmission case, rear axle case
Adhesive for preventing bolt & nut looseness
ThreeBond® 1324B or equivalent
Spiral bevel gear (ring gear) & differential case cap mounting bolt, PTO shaft sleeve
Preventing bolt & nut looseness, sleeve adhesion Section contacted with oil
ThreeBond® 1372
Differential pinion, side gear, differential and pinion gear
Initial lubrication, sticking
ThreeBond® 1901
shafts
prevention
Front axle case lower plug
Sealing and adhesion
Loctite® 5060
Elbow without O-ring in hydraulic line
Sealing and adhesion
Loctite® # 573
Hydraulic part filling plug
Sealing and adhesion
Loctite® TL-271
Auxiliary hydraulic tube's filter connector and hydraulic quick coupler connection
Sealing and adhesion
Loctite® # 572
docking section's stud bolt
ENGINE
Clutch housing, transmission case, rear axle case docking section
* Top link bracket anti-loose nut
A/C AND INDEX HEATER
HYDRAULIC ELECTRIC & DIAGNOSIS SYSTEM
HYDRAULIC STEERING SYSTEM
FRONT STEERING AXLE SYSTEM
FRONT BRAKE AXLE
REAR BRAKE AXLE
REAR HSTAXLE
TRANSMI HST
Dealer Copy -- Not forSSION Resale
TRANSMISSION TRANSMI SSION
CLUTCH
* Ball joint end connection
