ENGINE - ENGINE DISASSEMBLY AND SERVICING
GENERAL
11. Crankshaft and flywheel have their own reference hole on the mating surface. When installing the crankshaft and the flywheel, align the holes.
CLUTCH
ENGINE
NOTES
TRANSMI SSION TRANSMISSION
3
T46W2D3A
NOTES When installing the main bearing case cover, the "UP" mark on it should be at the highest position so that its holes are aligned with the holes of the cylinder block. 10. Tighten the outer bolts (3) first, then tighten the inner bolts (2).
M8.................................. 23.6 ~ 27.4 N•m 2.4 ~ 2.8 kgf-m 17.4 ~ 20.2 ft-lb
T46W2F8A
If the flywheel is turned from the original position and then installed, the bolts cannot be tightened. Align the installation reference holes (arrow �����������������K
