PDG0073
Located in the right-hand tool box of the undercarriage, this valve is used to shut off or enable stabilizer/dozer operation.
Selecting front stabilizers or dozer blade
Selecting front and rear stabilizers or dozer blade 1
PG02109
Place the valve lever in position (1). In this position, only the front stabilizers or the dozer blade can be operated using the lever in the operator’s compartment.
1
2 PG02107
Place the valve lever in position (1) + (2). In this position, the four stabilizers or the two stabilizers and the dozer blade can be operated simultaneously using the lever in the operator’s compartment.
95
TRIM THIS EDGE RIGHT PAGE
TRIM THIS EDGE
PG02111
Place the valve lever in position (2). In this position, only the rear stabilizers or the dozer blade can be operated using the lever in the operator’s compartment.
Template Name: OM_1_col Template Date: 1994_04_29
STABILIZERS/DOZER BLADE SELECTOR VALVE (depending on version) Selecting rear stabilizers or dozer blade
Alt= to hide template information Alt+ to display template information
CONTROLS/INSTRUMENTS/ACCESSORIES
