CONTROLS/INSTRUMENTS/ACCESSORIES
The steering column can be tilted forwards to clear the way for entering or leaving the operator’s compartment. IMPORTANT: When operating the machine, the steering column must always be tilted towards the operator and completely locked.
CD99M014
TRIM THIS EDGE
Use the lever to engage the locking system.
CD99M014
To tilt the steering column, turn the lever to disengage the locking system.
Alt= to hide template information Alt+ to display template information
TILTING THE STEERING COLUMN
CD99M016
- Hold the lever and press your thumb on the knob to release the lever. - Turn the lever to the desired position and release your thumb. CD99M015
IMPORTANT: In the locked position, the lever must never block access to the operator’s compartment.
Tilt the steering column forwards or backwards.
47
TRIM THIS EDGE RIGHT PAGE
Template Name: OM_1_col Template Date: 1994_04_29
The lever can be positioned over a radius of 360°. To do this:
