ELECTRICAL SYSTEM
BOOSTER BATTERIES Template Name: OM_1_col Template Date: 1994_04_29
!
WARNING: Incorrect connection of starter cables or short circuit between battery terminals can result in serious injury. Connect starter cables following the instructions below.
Tools required - Starter cables
2
1
4 3 TRIM THIS EDGE
PG03617
Check that the voltage of the booster batteries is compatible with the machine’s electrical system (24 volts).
Alt= to hide template information Alt+ to display template information
1.
Remove the shield.
2.
Remove caps.
3.
Connect the positive (+) starter cable (1) to the positive (+) terminal (2) of the first machine battery.
4.
Connect the negative (-) starter cable (3) to the negative (-) terminal (4) of the second machine battery.
5.
Start the engine.
6.
Disconnect the booster battery negative (-) starter cable (3) then the booster battery positive (+) starter cable (1).
7.
Install the terminal protection caps.
8.
Install the shield.
322
