MAINTENANCE/ADJUSTMENTS
The purpose of shimming attachments is to reduce and spread lateral play in the linkages and to keep the various components correctly aligned. Play is defined as the extent of possible lateral movement between one component and another at their linkage point. Shimming is carried out using steel shimming washers. IMPORTANT: The minimum play for all linkage points should never be less than 0.5 mm.
Shimming washers Part No. (1)
Part No. (2)
Part No. (3)
1 mm .............................................L3145352 .............M3145353 ..........N3145354 2 mm ..............................................L745347 ..............H3415326.............D745341 4 mm ...............................................U45443 ...................... - .................... L745440
Dipper top/Bucket TRIM THIS EDGE
Boom top/Dipper bottom
2 A 1 =
PDG0142
PDG0143
Measure the total play. If it is equal to or greater than 2 mm, insert washers (1) so as to obtain a minimum play of 0.5 mm.
Measure the total play. If it is equal to or greater than 2 mm, insert washers (2) so as to obtain a minimum play of 0.5 mm.
NOTE: Shimming must be symmetrical between the boom top and the dipper bottom.
To remove the pin, see “Replacing a backhoe bucket”.
IMPORTANT: Do not insert washers on the inner side of the dipper bottom (A).
NOTE: Shimming should be symmetrical between the dipper top and the bucket lugs.
305
TRIM THIS EDGE RIGHT PAGE
Template Name: OM_1_col Template Date: 1994_04_29
=
Alt= to hide template information Alt+ to display template information
SHIMMING OF ATTACHMENTS
