MAINTENANCE/ADJUSTMENTS
REPLACING AN EJECTOR BUCKET Removal Tools required A screwdriver A hammer A sleeve for threaded pins A wooden block A 30 mm diameter tube (longer than the width of the bucket and strong enough to support the weight of the ejector).
STEP 1 CD98D042
Put a wooden block under the bucket cylinder casing.
TRIM THIS EDGE
STEP 4
CD98D038
Block the ejector with the tube, extend the attachment and rest the bucket on the ground. STEP 2
CD98D038
Stop the engine and remove the starter switch key.
Remove the threaded pin, watching out for the yokes. Tilt the yokes rearward.
291
TRIM THIS EDGE RIGHT PAGE
Template Name: OM_1_col Template Date: 1994_04_29
-
Alt= to hide template information Alt+ to display template information
STEP 3
