LUBRICATION/FILTERS/FLUIDS
SWING REDUCTION GEAR Service specifications Template Name: OM_1_col Template Date: 1994_04_29
Oil level check ............................................................................... Every 100 hours Oil change ..................................................................................... Every 500 hours (after the first 250 hours of the run-in period) Oil capacity ................................................................................................... 5 liters Type of oil......................................................................See “Fluids and lubricants”
Oil level Tools required - One 27 mm wrench for hexagonal head screws STEP 1
TRIM THIS EDGE
Park the machine on flat, level ground, stop the engine and remove the starter switch key. STEP 2 PG03516
Remove the dipstick. The level should be between the “Maxi.” and “Mini.” marks. Add oil through this orifice, if necessary. STEP 3
Alt= to hide template information Alt+ to display template information
Install the dipstick.
PH07627
254
