JOB SITE AND ROAD OPERATION
IMPORTANT: (Specific to Germany), when travelling on the road, machines equipped with CASE clamshells must be driven without these tools. You must remove these tools before travelling on the road. This procedure for attaching the clamshell is given for a machine equipped with a 2.10 m dipper, with bucket cylinder and bucket control and a set of 10.00-20 tyres.
P, PL and P2A Versions STEP 1
STEP 2
Turn the clamshell to the vertical position so that its teeth are between the undercarriage front lugs.
2 1 PDH1079
Using the boom and dipper, position one shell of the clamshell on the attaching bar (1) at the front of the undercarriage.
TRIM THIS EDGE
1
Alt= to hide template information Alt+ to display template information
ATTACHING THE CASE CLAMSHELL FOR ROAD TRAVEL
173
TRIM THIS EDGE RIGHT PAGE
Template Name: OM_1_col Template Date: 1994_04_29
PDH1078
Install the attaching bar (1) in the bores (2) of the undercarriage front lugs. The split pin end of the bar (1) must be visible to the operator.
