JOB SITE AND ROAD OPERATION
!
WARNING: Before travelling on the road, make sure that the load on each axle, depending on the machine configuration, conforms to the road traffic regulations of the country concerned.
!
WARNING: All road travel must be undertaken in forward drive.
!
WARNING: Use of the electric travel control (if fitted) is strictly forbidden during road travel.
!
WARNING: (Specific to Germany), when travelling on the road, machines equipped with CASE clamshells must be driven without these tools. You must remove these tools before travelling on the road.
STEP 1
Alt= to hide template information Alt+ to display template information
!
WARNING: Before travelling on the road, you must lock the attachments and install the safety systems required by regulations. The stabilizers (if fitted) must be raised completely and immobilized using the lock pins and split pins. The stabilizer pads must be in the swivel position. The dozer blade (if fitted) must be raised and immobilized using the lock pin and split pin.
TRIM THIS EDGE
ROAD TRAVEL
CD98J005
Raise the stabilizers (if fitted) completely.
CD99N045
Immobilize the stabilizers using the lock pins and split pins located in the tool box.
163
TRIM THIS EDGE RIGHT PAGE
Template Name: OM_1_col Template Date: 1994_04_29
STEP 2
