OPERATING INSTRUCTIONS
TOOL INSTALLATION AND REMOVAL USING THE QUICK COUPLER (optional) Template Name: OM_1_col Template Date: 1994_04_29
!
WARNING: Never put your hands in the Quick Coupler while the engine is running.
Installation IMPORTANT: When installing the Quick Coupler hydraulic system, the connecting rod must be mounted at the maximum opening range point.
STEP 3
STEP 1
TRIM THIS EDGE
CK97A004
1
Make sure that the tool linkage pin is placed at the maximum opening range position.
CK97A003
Alt= to hide template information Alt+ to display template information
Install the Quick Coupler on the dipper and on the connecting rod using the pins supplied by CASE (1), and then connect the supply lines.
IMPORTANT: The pin must be placed at the maximum opening range position, otherwise the tool cannot be hooked onto the Quick Coupler. STEP 4
STEP 2 Make sure that the tool to be installed is in a safe position on flat, level ground, and equipped with genuine CASE pins.
CK97A009
Remove the split pin and retaining pin.
150
