OPERATING INSTRUCTIONS
1
2
This decal shows the center of gravity of the machine in relation to the rear wheel axis. The distance (D) from the center of gravity varies according to three possible handling configurations.
3
(1) Machine without boom, without cab and without counterweight. (2) Machine without boom, with cab and with counterweight. PDH1147
WARNING: The position of the sling points shown in the decal above must be observed.
P2A Version (except Germany) (4 wheel configuration 18-19,5XF) Distance (D)
Machine weight
(1)..................................................... 754 mm ..........................................10 402 kg (2)..................................................... 312 mm ..........................................14 288 kg (3)..................................................... 687 mm ..........................................15 958 kg
TRIM THIS EDGE
!
(3) Machine with monoblock boom 5.20 m, with cab and with counterweight.
Alt= to hide template information Alt+ to display template information
HANDLING THE MACHINE
P2A Version (only Germany) Machine weight
(1)..................................................... 774 mm ..........................................10 802 kg (2)..................................................... 399 mm ..........................................14 046 kg (3)..................................................... 771 mm ..........................................15 716 kg NOTE: For the other machine versions, consult your CASE Dealer to obtain the distance (D). For the machine weight, see “Weights” in the “Specifications” Section.
!
WARNING: Do not handle the machine equipped with its dipper.
139
TRIM THIS EDGE RIGHT PAGE
Template Name: OM_1_col Template Date: 1994_04_29
Distance (D)
