CONTROLS/INSTRUMENTS/ACCESSORIES
FUEL TANK FILLER PUMP (optional) Template Name: OM_1_col Template Date: 1994_04_29
!
WARNING: Never refuel when the engine is running. Never smoke while refuelling.
IMPORTANT: This pump is located in the upperstructure tool box and should only be used for fuel.
STEP 3
1
STEP 1 Park the machine on flat, level ground. Stop the engine and remove the starter switch key. STEP 2
PDF0361
TRIM THIS EDGE
Measure the height of the drum and place the suction tube sight ring (1) at a height slightly lower than that of the drum. STEP 4
Alt= to hide template information Alt+ to display template information
PE11716
Remove the filler cap from the fuel tank.
!
WARNING: The filler cap must be removed before filling the tank. This will prevent the risk of accidents when opening the filler cap after filling. PDF0362
Make sure that the screen on the end of the suction tube is correctly attached, and then lower the suction tube into the drum.
112
