OPERATIONAL PERFORMANCE TEST /System performance Measurement:
CAUTION:Avoid measurement in reverse travel operation, as it is too dangerous. 1. Measure in each mode (slow and fast). 2. Select the switch positions as follows: 3.Start traveling the machine from the acceleration zone with the FNR shift lever in the forward position and the accelerator pedal at full stroke. Measure the time (sec) required to travel 20 m (65 ft) in each travel mode. 4.Repeat the measurement three times in both travel modes and calculate the average value. 5.Covert the measured value to the value in km/h unit using the following formula: Measure Value = S (sec) Converted Value = A (km/h) A = (20 × 3600)/(S × 1000)
Evaluation: Refer to the Performance Standard Table Remedy: Refer to Troubleshooting
