OPERATIONAL PERFORMANCE TEST / Engine Valve Clearance Summary: 1. Perform measurement when the engine is cold. 2. Before starting work, clean the head cover mounting area to prevent contaminating the engine. Preparation: 1. Locate top dead center (TDC) in the compression stroke. Align the 1.4TC mark on the crank pulley with the pointer on the timing gear case. Piston No.1 (or piston No.4) is now positioned at TDC in its compression stroke. 2. Remove the head cover (after cleaning). 3. When both the intake and exhaust valves on cylinder No.1 are closed, piston No.1 is positioned at the TDC in its compression stroke. (When both the intake and exhaust valves are closed on cylinder No.4, piston No.4 is positioned at TDC in its compression stroke.) Start measurement from cylinder No.1 or No.4 positioned at the TDC in its compression stroke.
)GCT %CUG
6% /CTM 2QKPVGT %TCPM 2WNNG[
Measurement: 1. Insert a feeler gauge into the clearance between the rocker arm and the valve stem end to measure the valve clearance.
#FLWUVKPI 5ETGY .QEM 0WV 4QEMGT #TO (GGNGT )CWIG
㪥㪦㪫㪜 The cylinders are arranged from No.1 to No.4 in that order, as viewed from the fan side. 8CNXG 5VGO
