COMPONENT OPERATION ／ Control Valve ・Oil flow in TILT plunger section NEUTRAL position of the TILT and LIFT sections １．As the spools of the the tilt and lift sections are in the "NEUTRAL", the cylinder ports at both A (Rod side) and B (Bottom side) are closed by the spools. ２．The oil is sent to the control valve that passes from the inlet section through the neutral passage (3) of the tilt section and lift section, then it goes out from the drain passage (4) to the oil tank.
㧝
㧞 㧭㧝
㧮㧝
㧞
㧟
㧠
1-Load check valve 2-Oil discharged from the pump 3-Neutral passage to the lift section 4-Drain passage to the oil tank
３ ‑136
