COMPONENT OPERATION ／ HST Motor ・ＨＤ Controller（Automatic drive ）（UCHIDA ／ Serial No. 4501 〜） In this case, the hydraulic force due to the pilot pressure [Px] is larger than the force due to the springs (3) and (4). Thus the pilot piston (1) is located at the position shown in the figure to transfer the pressure of the primary side of the control bush [A] to the secondary side of the control bush [B].In addition, the cut-off valve (12) moves to the position as shown in the figure to transfer the pressure of the secondary side of the control bush [B] to the larger diameter side of the control piston [D], because the hydraulic force of the primary side of the control bush [A] which is applied to the cut-off valve (12) is smaller than the force due to the spring (13).As a result, a hydraulic force due to the difference in section area between large [D] and small [C] diameters of the control piston is applied to the control piston (5), and it is moved to the side of small tilt shown in the figure.
