Chassis — Lift Arm Installation Lift Arm Installation
STEP 2
5
STEP 1
5
1
6
6
Align the lift cylinders with lift arm. Install pins (5). Install the retaining bolts (6) and nuts and tighten to 33 lb-ft (45 N•m). Remove lifting straps.
2 7
2
3 4
STEP 3
4
7 8
Using the proper lifting strap (7) and appropriate lifting device, install the tilt cylinder (8). STEP 4
Using proper lifting straps (1), move lift arm into place. Install upper mounting pin (2). Install retaining bolts and nuts (3) and tighten to 33 lb-ft (45 N•m). Install hydraulic hoses (4).
9
10
Reconnect work light
11 9 10 Install pins (9) on tilt cylinder. Install retainer bolts and nuts (10) and tighten to 33 lb-ft (45 N•m). Install and tighten hydraulic hoses (11) on tilt cylinder. Remove lifting strap. PRINTED IN U.S.A.
75
50940008/AP0311
