Operation — Lift/Tilt Lock Lift/Tilt Lock
AL 500 Series Machines
AL 400 Series Machines
1. Remove the quick-release pin (1, Figure 15), and lift the cylinder stop channel (2) off the machine.
1. Remove the spring pins (1, Figure 14), and remove the lock bar (2) from the machine.
2 1 2
1
1
1
1
2
2
1
3 4 Figure 15 – AL 500 Series Lift Arm Lock Figure 14 – AL 400 Series Lift Arm Lock
2. Tilt the attachment/hitch back as required and place the cylinder stop channel (2) under tilt indicator (1) and over the tilt cylinder to brace the tilt cylinder in the extended position.
2. Tilt the attachment/hitch as required to align holes in tilt bracket (3) with holes in lift arms (4). Slide the lock bar (2) all the way through the locking holes (3) in the lift arm, the tilt cylinder linkage and the front frame.
3. Replace the quick-release (1) into the cylinder stop channel so it passes under the tilt cylinder rod.
3. Replace the spring pins (1) into the ends of the lock bar.
