Operation — Steering Column Steering Column
Control Lever
Steering Column Adjustment
The control lever on the steering column controls the following functions:
WARNING Never adjust the steering column when the engine is running.
1 3
Adjust the steering column for visibility, usability and comfort.
2
Figure 10 -- Control Lever 1. Horn 2. Lights 3. Turn signals
1. Push the control lever in to activate the horn (1, Figure 10). 2. Twist the end of the control lever to activate the position lights (2). 3. Push the control lever forward or rearward to activate the turn signals (3).
1
4. Push the control lever downward to activate “high” beam (driving light). 5. Pull the control lever upward to activate “low” beam (dipped-beam light). .
Figure 9 -- Steering Column Adjustment 1. Push the adjustment lever (1, Figure 9) downward.
1
2. Adjust the steering column to the desired position.
2
3. Release the adjustment lever.
3
4. Check that the steering column is locked in place.
Figure 11 -- Road Light 1. “High” beam (driving light) 2. “Low” beam (dipped-beam light) 3. Marker/turn signal
