Operation — Warning Indicators Warning Indicators
IMPORTANT: If any of the following indicators illuminate when the engine is running, turn off the engine immediately. Correct the problem before restarting the engine. During normal operation these indicators should be OFF.
3 1
4
5
2
Figure 6 - Warning Indicators No.
Indicator
Description
1
Engine coolant temperature warning
Temperature is too hot.
2
Voltmeter
Alternator overheat - 6 bars illuminate.
3
Engine oil pressure
Pressure is too low.
4
Hydraulic oil temperature
Temperature is too hot.
5
Hydraulic oil filter
Hydraulic oil filter service required.
50940008/BP0311
