Operation — Instrument Panel and Indicators Instrument Panel and Indicators 17
16
1
2 3
15
4
14 13
5
18 19 12
6
7
11 20 21 10
8 9
No.
Indicator
Description
1
Forward travel
Drive direction thumb switch on joystick is in forward position – the machine will move forward when the travel pedal is pressed when this lamp is lit.
2
Pre-heat
Illuminates when the ignition key is in the “I” (Run) position. Goes out when the glow plugs have heated sufficiently to start the engine.
3
Engine oil temperature warning
See page 56.
4
Hydraulic oil filter
See page 56.
5
Differential lock
Differential lock engaged.
6
Right turn/hazard lights
Right turn signal engaged. Hazard lights.
7
Parking brake
Parking brake engaged.
8
Road lights
Road lights upper beam engaged.
9
Rearward travel
Drive direction thumb switch on joystick is in Reverse position – the machine will move in reverse when the travel pedal is pressed when this lamp is lit.
10
Alternator
Alternator not charging.
11
Slow speed
Low-speed drive engaged.
