Operation — Controls and Switches No.
Item
Description
1
Steering knob
Use to turn steering wheel.
2
Instrument panel
Contains warning indicators, operation indicators, and gauges.
3
Steering wheel
Turn to control travel direction.
4
Accelerator pedal
Press to control engine/travel speed.
5
Multi-purpose joystick
Use to control lift arm/attachment maneuvering and loader drive direction.
6a
Auxiliary hydraulics control lever
Use to activate auxiliary hydraulics control circuit. On early machines, the control lever is located next to the joystick. Use to activate auxiliary hydraulics control circuit.
6a
Auxiliary hydraulics control buttons
7
Parking brake lever
Use to engage parking brake.
8
Operator’s seat
Adjust operator’s seat position (page 57).
9
Brake/inch pedal
Press to control gradual travel and braking.
10
Steering column tilt
Use to adjust steering column tilt (page 58).
11
Hazard light switch
Press to activate hazard lights.
12
Work light switch
Press switch to ON position to activate work lights.
13
Rotating beacon switch (option)
Press switch to ON position to activate rotating beacon.
On later machines, auxiliary hydraulics flow is controlled using buttons on the front of the joystick.
Use switch to connect/disconnect the battery and electrical circuit. 14
Battery disconnect switch (option; standard EU only)
On early machines, the battery disconnect switch is located on the operator’s platform under the seat. On later machines, the battery disconnect switch is located inside the engine compartment.
15
Seat belt
Always fasten seat belt before operating loader.
16
Control lever
Controls road lights, directional indicators and horn.
17
Power-A-Tach® lock/unlock (option)
Use to lock/unlock attachment.
18
Drive direction switch
Use to control forward/reverse drive direction.
19
Seat plate
Seat plate according to ISO 7096 (located on seat).
20
Hand throttle
Controls engine speed independently from the accelerator pedal. Does not control travel speed. Toggles between slow/fast travel speed. Indicators 11 and14 illuminate to show selection.
21
Slow/fast speed toggle switch
On early machines, this switch is located on the top right of the joystick. On later machines, this switch is located on the top left of the joystick. Engages differential lock when depressed. Indicator 5 illuminates when the differential lock is engaged.
22
Differential lock momentary or slow/fast selection switch
On early machines, this switch is located on the front of the joystick. On later machines, this switch is located on the top right of the joystick.
23
Auxiliary Electrical circuit momentary switch (option)
