Maintenance — Electrical System Fuse Blocks (s) - Engine Compartment NOTE: Early machine have a fuse block located at the right rear corner of the operator’s platform, inside the engine compartment. Later machines do not have this fuse block; fuses are located underneat the operator’s plaform. See “Cab and In-Line Fuses (Later Machines)” on page 37. On cab-equipped machines a fuse block, also located at the right rear corner of the operator’s platform inside the engine compartment, holds fuses for cab electronics.
Early machines only. These fuses are located inline on later machines. See “Cab and In-Line Fuses (Later Machines)” on page 37.
STANDARD FUSES
CAB FUSES
5
1
6
2 7
3 8 4
Figure 33 – Fuse Panels, Engine Compartment Fuse No.
Rated Current (Amp)
1 2 3 4 5 6 7 8
15 40 25 25 5 5 10 25
50940008/AP0311
Protected Circuit Drive Module Glow Plugs Control Module Starter Solenoid Dome Light Rear Wiper Motor Front Wiper Motor Heater
40
