Maintenance — Fuel System 7. The engine is self-priming. To remove air before starting, turn the ignition key to the ON position for 30 seconds.
ON
Water Separator Maintenance
OFF 1
The water separator contains a red indicator ring that will float on top of any accumulated water. Under normal conditions this ring sits at the bottom of the separator. If the red ring is somewhere between the bottom and the white ring (2, Figure 11), then the accumulated water must be drained. 1. Perform the “Mandatory Procedure” on page 4.
Safety
2
Shutdown
2. To view the water separator, use the slot in front of the right-rear tire, near the step.
3 Figure 11 – Water Separator
3. Access the water separator underneath the loader, near the right-rear wheel. Check for water in water separator by checking level of float in water separator bowl. If water is present, complete steps 4-7.
1. Fuel Shut-off Valve Lever 2. Indicator Ring 3. Drain Plug
4. Turn the fuel shut-off valve lever (1, Figure 11) on the water separator to the OFF position. 5. Place a container underneath the drain plug. Loosen the plug until water begins draining. Allow water to drain until the indicator ring returns to the bottom of the water separator. 6. Tighten the drain plug and discard fuel/water according to environmental laws. DO NOT pour the fuel/water onto the ground or down a drain. 7. Turn the fuel shut-off valve lever (1) on the water separator to the ON position.
