Drive Control System— Plus+1 Service Tool Navigation/Overview STEP 6 Plug the USB cable on the “CAN HS” cable into a USB port on the computer that has the PLUS+1 GUIDE Service Tool software installed.
4. After the service tool starts, select “Gateway > CG150>Sauer Danfoss CG150 #0 (Channel0)” from the “Communication” menu.
The first time the USB cable is plugged into the computer, a “Found New Hardware Wizard” window displays. 1. Select the “Install the software automatically” radio button and click “Next”.
Plus+1 Service Tool Navigation/ Overview The “Diagnostic Navigator” is located in the left pane of the service tool window. Selecting items in this pane provides access to functions and data points inside the PLUS+1 module on the machine.
a 2. The system will find and install the proper software located on the PLUS+1 module. b
c
3. Click “Finish” when the “Completing the Found New Hardware Wizard” message displays.
a. The “*ConnDiagram*” PDF document resides inside the PLUS+1 module. This document shows a diagram of the pin assignments for the two 12-pin input/output connectors on the module. b. The “Log Functions” section allows: •
Real-time access to drive system inputs and outputs, allowing for monitoring the drive system while the machine.
•
Detailed error information access – includes both active errors and error history.
c. The “Parameter Functions” section allows: • 50940008/AP0311
174
Pedal calibration/re-calibration. PRINTED IN U.S.A.
