Drive Control System— Service Communication Kit and PLUS+1 Service Communication Kit and PLUS+1 GUIDE Service Tool Software
STEP 2 Connect the two harnesses in the kit together. STEP 3
The 203907 service communication kit provides a physical connection between the drive controller and a computer. The kit also provides diagnostic and calibration software and instructions for it’s use. NOTE: For additional information about the PLUS+1 service tool, its features and functionality, visit the Sauer-Danfoss website at: http://www.sauerdanfoss.com.
PLUS+1 Service Tool/Module Communication Connection Remove the cover from the two-pin service connector on the PLUS+1 module. Plug the harness into the service connector.
STEP 1
STEP 4 Turn the ignition key on the loader to the “1” (Run) position to activate the PLUS+1 module. STEP 5
Remove the screw and the strap securing the PLUS+1 module service cover on the loader. Remove the cover. Double click the “PLUS+1 GUIDE Service Tool 4.1” icon on the desktop to launch the PLUS+1 service tool software. NOTE: Service Tool software installation is required before the service tool can be used.
