Drive Control System— Machine Controller Function
“IN” LEDs
“OUT” LEDs
(1) -- Ignition switch in "RUN" position
Notes
The engine will run only if:
Later serial number machines: Later serial number machines: (13, 24) -- (24) Seat switch indicates The operator seat is occupied and/ Engine Run operator in seat and/or (13) parking (26) -- Signal sent to fuel solenoid to or the parking brake is on Safety brake engaged maintain fuel flow Early serial number machines: The operator seat platform is down and/or the parking brake is on
Earlier serial number machines: (12, 13) -- (24) ROPS tilt switch indicates operator platform is down and/ or (13) parking brake engaged
Lift/Tilt Safety
Later serial number machines only
(1) -- Ignition switch in "RUN" position
(22) -- Signal sent to lift/tilt lock soleThe lift/tilt functions are enabled noids (24) -- Seat switch indicates operator only with the ignition in the “RUN” in seat position and the operator seat occupied Later serial number machines
(1) -- Ignition switch in "RUN" position (24) -- Seat switch indicates operator Auxiliary in seat (20) -- Signal sent to Forward auxilHydraulics iary hydraulics solenoid Flow (For- (25) -- Forward direction auxiliary hydraulics joystick button is pressed ward) (23) -- Reverse direction auxiliary hydraulics joystick button is pressed (for continuous flow)
Forward auxiliary hydraulics flow is activated if the ignition switch is in the “RUN” position, the operator seat is occupied and the forward direction auxiliary hydraulics joystick is pressed Continuous forward hydraulics flow is activated if the reverse direction hydraulics joystick button is then pressed, and both buttons are held for two seconds. Forward hydraulics flow will then continue after the buttons are released Continuous forward hydraulics flow is deactivated if either button is momentarily pressed
