Hydraulics — Tilt Cylinder Removal Tilt Cylinder Removal
Tilt Cylinder Installation
STEP 1
STEP 1
CAUTION
1 2
Support the attachment connection plate so that it doesn’t fall when the tilt cylinder is removed.
STEP 2
3
5
2
Install a lifting strap (1) on the tilt cylinder (2). Use an appropriate lifting device to lift the cylinder into place.
1
STEP 2
5
3
4
3
2
4
5 4
3
Install the pins (3). Install bolts and nuts (4) tighten to 33 lb.-ft. (45 N•m). Install two hydraulic hoses (5) on the tilt cylinder (2). Remove lifting strap.
Remove and plug two hydraulic hoses (1) from the tilt cylinder (2). Remove bolts and nuts (3). Install a lifting strap (4) on the tilt cylinder. Use an appropriate lifting device to support the cylinder. Remove pin (5). Place an absorbant mat under the cylinder to catch any dripping oil. Remove cylinder.
NOTE: Cylinder plugs will need to be removed to move rod for alignment with pin. STEP 3 Start the machine and bleed the air out of the cylinder by cycling the cylinder through full extension and retraction three times. STEP 4 Check the hydraulic fluid level and fill as needed. See “Hydraulic System Maintenance” on page 29.
