Operation of the machine
2.5.17 Conveyor It serves for distributing the material to augers. The conveyor function is only active in working mode. Conveyor movement directions: •
When distributing the material, the conveyor moves in the opposite direction of the machine travel.
•
When reversing, the material conveyor moves in the direction of the machine travel.
•
The conveyor direction can be affected by the conveyor direction switch (18).
D451042 Operating modes: •
Automatic mode:
STOP
12V
•
-
When the machine stops, the material distribution will stop.
-
The material limit switch monitors the amount of the delivered material and as needed, stops or starts the movement of the conveyor.
-
The mode is only active during machine travel.
-
The conveyor direction can be affected by the conveyor direction switch (18).
0V
14V
Manual mode: -
Monitor the amount of the material and if necessary adjust the direction of the conveyor by the conveyor direction switch (18).
18 17
452024
Operating the conveyor: •
•
92
Automatic mode: -
For the automatic mode, switch over the material delivery operating mode switch MAN/AUT (17) to the automatic mode position.
-
For material distribution, switch over the conveyor direction switch (18) to the lower position.
-
For reverse run, switch over the conveyor direction switch (18) to the upper position.
-
To stop the conveyor, switch over the conveyor direction switch (18) to the central position.
Manual mode: -
For the manual mode, switch over the material delivery operating mode switch MAN/AUT (17) to the manual mode position.
-
For material distribution, switch over the conveyor direction switch (18) to the lower position.
-
For reverse run, switch over the conveyor direction switch (18) to the upper position.
-
To stop the conveyor, switch over the conveyor direction switch (18) to the central position.
Caution! When the conveyor direction switch (18) is activated in the lower position, the conveyor moves in the manual mode even if the machine is not moving. Caution! When the conveyor direction switch (18) is activated to the upper position, the conveyor starts moving in the automatic mode only after the machine starts moving.
