2.5
Operation of the machine
2.5.10 Travel and reversing of the machine STOP
12V
The machine may be operated in the transport or operating mode. The transport or operating mode are set by the switch of the transport and operating mode (15).
0V
8
12 1
The travel of the machine backwards is only possible in the transport mode.
Travel of the machine in the transport mode: •
Check that the emergency switch (1) is not activated.
•
Turn the transport and operating mode (15) switch to the transport mode position (rabbit).
•
Start the engine according to Chapter 2.5.8.
•
Travel control in the neutral position (N). The indicator lamp (23) lights on the display.
•
Set the maximum engine speed using the engine speed switch (10).
•
Pull the arresting ring of the travel controller (8) up and move the travel controller forward.
•
The indicator lamp (25) lights on the display.
•
Before reversing, make sure the screed is not on the ground or close to the ground.
•
To travel the machine backwards, operate the foot switch (48); the travel control is in the neutral position, the indicator lamp (27) will light up, then pull up the arresting ring of the travel control (8) and move the travel control backwards.
•
The indicator lamp (27) lights on the display and the indicator lamp (25) will go out.
•
An acoustic signals is emitted by the reversing horn when the machine travels backwards.
•
The maximum travel speed forward and backward is 2,2 km/h (1,37 MPH).
•
During the travel the front wheel turning angle indicator (4) checks the turning angle.
14V
14
11 15 10
452019
48 D451686
27
25 STOP
23
12V
0V
14V
Travel of the machine in the operating mode: •
Check that the emergency switch (1) is not activated.
•
Switch over the transport and operating mode switch (15) to the operating mode position (turtle).
•
Set the required speed using the paving speed selector (14),
•
Start the engine according to Chapter 2.5.8.
•
Travel control in the neutral position (N). The indicator lamp (23) lights on the display.
•
Set the maximum engine speed using the engine speed switch (10).
•
Pull up the arresting ring of the travel control (8) and move the travel control forward.
•
The maximum travel speed forward is 0.7 km/h (0.43 MPH).
•
The machine backward travel function cannot be activated in the operating mode.
84
452003
F80W
