2.5
Operation of the machine
2.5.6
Beacon
1
The machine is delivered from the manufacturer with a beacon dismounted. Before starting the operation of the machine the beacon must be mounted on the machine.
Turning on the beacon: •
When the engine is started, the beacon (1) will be automatically turned on.
Turning off the beacon: •
Turning the key in the ignition box to the “0” position automatically turns off the beacon (1).
2
451060A
Mounting the beacon: •
Mount the beacon (1) on the beacon holder (2).
•
Mount the beacon holder (2) on the machine and secure it using a wing nut (3).
Connecting the electrical wiring to the beacon: •
2
Insert the plug of the beacon (4) to the mounting socket 12 V (5) on the main dashboard (6).
3 D451700 It is forbidden to operate the machine without the beacon mounted on.
6
5 4 D451701
80
F80W
