Page 58

2.1

Main safety precautions

Prohibited activities during machine operation: •

Operating the machine without personal protective equipment.

Operating the machine if any defects are found, if the machine is not serviceable and if all safety conditions for machine operation are met.

Operating the machine if its operation endangers safety of people, its technical condition and property.

Operate the machine if any safety devices, e.g. an emergency brake of the machine, are dismounted or damaged.

Operating the machine when any of the operating fluid levels is low.

Operating the machine with leaking oil, fuel, coolant or other operating fluid.

Operating the machine on the slope with inclination and side static stability higher than stated in this Operating Manual.

• • •

Use the machine emergency brake function to stop the engine during machine operation when there is no danger threatening people or the machine.

Performing maintenance, cleaning and repairs without personal protective equipment.

Performing maintenance, cleaning or repairs with the machine not secured against spontaneous movement or accidental start, and if a person can come in contact with moving parts of the machine.

Failing to observe prescribed machine maintenance intervals.

Failing to observe or omitting instructions at repairs and maintenance of the machine stated in this Operating Manual.

Repairing or maintaining the engine in a different way than according to prescribed tasks in this Operating Manual; special repairs can only be performed by an authorised service centre.

Operating the machine in explosive environment.

Starting the engine in a different way than stated in this Operating Manual.

Disabling safety, protective or locking systems or altering their parameters.

Removing impurities by high-pressure cleaners.

Removing impurities during machine operation.

Touching moving parts of the machine with the human body or items and tools held in hands. Smoking or handling an open flame when checking and pumping fuels, replacing or refilling operating fluids, lubricating the machine, inspecting and refilling the battery.

Only an authorized service centre can interfere in any manner with electrical and electronic parts and cable harnesses, the machine is equipped with and carry out special repairs.

Using free connectors to connect other devices.

Performing any modifications on the machine without the prior written consent of the manufacturer Dynapac.

Performing maintenance and repairs of the machine using non-original parts.

Transporting and storing tools and other objects at the driver's place.

Transporting and storing objects at places inside the machine which are not intended as deposition boxes.

Transporting and storing cloths soaked with flammable substances and flammable liquids in/on the machine.

Using diesel instead of an anti-adhesion solution to ensure non-adherent surface of the hopper area.

52

Prohibited activities during repairs and maintenance of the machine:

F80W
