1.3
Technical data
1.3.3.7 Screed copying system The screed copying system (2) is used to set a constant paving thickness with the guide surface (e.g. the original paved layer). Before paving, fill the area in front of the screed with a sufficient amount of paving material. During paving with the copying system (2), the operator must maintain a sufficient amount of paving material in front of/under the screed. Insufficient material supplied by the conveyor may result in uneven road (waves, pits).
2
2
K451009 Install the screed copying system (2) according to the installation instructions. When operating the screed copying system (2), do not turn on vibration.
Screed copying system set Order number: 4812335000 The screed copying system set consists of: copying system 2x (1) angle plate 2x (2) installation material.
When installing the screed copying system (2), the machine must be standing on a level and firm surface with the engine switched off. Use personal protective equipment.
26
F80W
