1.3
Technical data
1.3.3.5 Material hopper extension The material hopper extension serves for enlarging the filling space and easier feeding of material to the machine. The material hopper extension consists of two plates (1) and (2), which are fitted with two fork-shaped holders (3)
1 2
3 Mount the material hopper extensions according to the Mounting Manual.
D451818A Material hopper extension kit Order number: 4812061019 The material hopper extension kit consists of the following components: •
Material hopper extension – left (2),
•
Material hopper extension – right (1),
During mounting of the material hopper extension the machine must be parked on a flat and solid surface with the engine and battery disconnecter off. It is prohibited to use the material hopper extension as a container extension. Use personal protective equipment.
24
F80W
