1.3
Technical data
1.3.3.3 Dual wheels
1
Dual wheels serve for the improvement of machine traction and stability. A dual wheel, which is part of the dual wheel set, is identical with the standard rear wheel. Distance between external surfaces of rear wheels: •
With standard rear wheels: 765 mm (30.1 in).
•
With dual wheels: 1,077 mm (42.4 in).
2 451816 Mount the dual wheels according to the Mounting Manual.
Dual wheel kit: Order number: 4812061018
3
The dual wheel kit consists of the following components: •
Two dual wheels (1),
•
Two dual wheel supports (2),
•
Two dual wheel cover plates (3),
•
Mounting material.
451017A
During mounting of dual wheels the machine must be parked on a flat and solid surface with the engine and battery disconnecter off. Use personal protective equipment. Use twin wheels only with wheels from the base of the machine. It is forbidden to operate the machine only on the outer auxiliary wheels.
22
F80W
