1.3
Technical data
1.3.3.2 Mechanical screed extension The mechanical screed extension serves for extending the paving width. The maximum width of the screed is 1,300 mm. After installing the mechanical screed extension set, the maximum screed width will increase by 350 mm to 1,650 mm. Paving width with mechanical extension is: •
Minimum paving width with mechanical extension: 1150 mm (45.3 in).
•
Maximum paving width with mechanical extension: 1650 mm (65 in).
Mount the mechanical screed extension according to the Mounting Manual.
1
2 451815
3
4
Mechanical screed extension kit Order number: 4812061017 The mechanical screed extension kit consists of the following components: •
Mechanical screed extension – left (1),
•
Mechanical screed extension – right (2),
•
Auger extension – left (3),
•
Auger extension – right (4),
•
Mounting material.
451814
During mounting of the mechanical screed extension the machine must be parked on a flat and solid surface with the engine and battery disconnecter off. Use personal protective equipment.
20
F80W
