3.6
Lubrication and maintenance operations
3.6.26 Air filter replacement Perform air filter replacement when the machine is parked on a flat and solid surface with the engine and battery disconnecter off. Air filter replacement procedure: •
Open the left material hopper side cover (1).
•
Open the engine bonnet (2).
•
Unlock the air filter cap (3) and remove the inlet air filter cover (4).
•
Remove the nut (5) and the air filter (6).
•
Tighten the inlet openings (7) and (8) are free of dirt and foreign objects.
•
Clean the air filter body (9) and the air filter cover (4).
•
Mount a new air filter (6) and screw the nut (5).
•
Mount the air filter cover (4) ad lock the air filter cap (3).
1 2 D451126
4
Perform air filter replacement when the machine is parked on a flat and solid surface with the engine and battery disconnecter off. When replacing the air filter, use the prescribed protective equipment. There is a risk of burns from the hot parts of the engine.
3
D451127A
Do not use compressed air to clean the air filter body and cover; there is a risk of ingress of foreign objects to suction holes of air inlets.
5
6
D451143
Hand over the dismounted air filter for disposal according to the national regulations.
9 8
7
D451144 168
F80W
